DP600-A is a new generation Automatic taping machine, which is designed to be simple and easy operated; tape width adjustment can be finished within 10 seconds without any tool. DP600-A supports devices packaged in 8~88mm width tape. With advanced characteristics DP600-A offers the best solution for manufacturing process.
Highlights:
Mechanical Accuracy +/- 0.04 mm.
Support up to 22" (550mm) input and 13" (330mm) output tape reel.
Supported 8~88 mm width cover tape
Supported 32 mm depth carrier tape.
RS232 interface easily communicates with third party automated system.
PSA (Press sensitive adhesive) and heat sealing.
CE Certificate.
DP600-A là máy băng keo tự động thế hệ mới, được thiết kế đơn giản và dễ vận hành; Điều chỉnh độ rộng băng có thể được hoàn thành trong vòng 10 giây mà không cần bất kỳ công cụ nào. DP600-A hỗ trợ các thiết bị được đóng gói trong băng có chiều rộng 8 ~ 88mm. Với các đặc tính tiên tiến DP600-A mang đến giải pháp tốt nhất cho quá trình sản xuất.
Điểm nổi bật :
Độ chính xác cơ học +/- 0,04 mm.
Hỗ trợ cuộn băng đầu vào lên đến 22 "(550mm) và 13" (330mm).
Băng bìa có chiều rộng 8 ~ 88 mm được hỗ trợ
Băng mang độ sâu 32 mm được hỗ trợ.
Giao diện RS232 dễ dàng giao tiếp với hệ thống tự động của bên thứ ba.
PSA (Keo dán nhạy cảm với báo chí) và keo nhiệt.
Chứng chỉ CE.
Mã số :
Kiểu loại :
Packing machine
Mô tả chi tiết :
Checking Systems
Cover Tape Sensor: The sensor will alarm when running out of cover tape.
Empty Pocket Sensor: Check if each pocket has carried an IC.
Floating Chip Sensor: Check the floating IC.
Carrier Tape Sensor: The sensor will alarm when running out of cover tape.
High Compatible
DP600-A is fitted with RS232/IO port for easy integration with the most automated system. It has optional IC marker and CCD inspection devices thus allow DP600-A not only support automated system integration but also benefits the quality assurance, marking and packaging procedures in a production line.
2D Inspection System
Use CCD to check IC Appearance
Ink Marker
Stamp dot, number or letter on the IC with different colors.
Standard Package
DP600-A Main Unit x 1
User Manual x 1
Optional Accessories
Ink Marker
2D Inspection System
