Category: Main/1. Device Programmer - Introduction and Guide/1.2. Gang Programmers
| | | | | ◊ Đặc điểm chính: | | ProgMaster-U8 is a new generation universal gang programmer with ultra high speed which supports all IC families on the market. Equipped with 8 programming sites with a LCD keypad that allows stand-alone function. ProgMaster-U8 has been designed and optimized to reach IC maximum performances without compromise on the programming quality, stability and reliability and making it the best value for mass production.
|
|
|

ProgMaster-U8 with Hand Press Fixture: It helps you to push down 8 sockets easily and simultaneously.
Feature
ProgMaster-U8 is a gang programmer with ultra-high speed, which supports all IC families on the market. Equipped with 8 programming sites with an LCD keypad that allows stand-alone function. ProgMaster-U8 has been designed and optimized to reach IC maximum performances without compromising on the programming quality, stability, and reliability and making it the best value for mass production.
Highlights
- High programming speed
- Built-in high-speed processor to achieve high programming speed.
| |
Timing Reference (P+V) |
|
| |
MX25L1655D |
8s |
|
| |
S29GL064S |
16s |
|
| |
S34ML01G200T |
48s |
|
| |
STM32F302CCT |
9s |
|
| |
ST BlueNRG-132 |
21.5s |
|
- Completely support all IC families and packages
- EEPROM, MCU, SPI NOR/NAND Flash, Parallel NOR/NAND Flash, eMMC/eMCP, CPLD, FPGA...etc.
- DIP, SOP, SSOP, TSOP, PLCC, QFN, BGA...etc.
- Regular software update.
- The software supports NAND FLASH skip Bad Block and partition programming.
- Built-in memory card slot for project programming
- Able to save project files to SD cards for more stable and faster transmission.
- One computer can connect to multiple ProgMaster-U8 at the same time.
- The stand-alone function allows you to program without a computer and only need to select and start the project programming through an LCD keypad.
- Exclusive design for productivity improvement
- You can start programming once the project file is loaded; it will also avoid the human errors when importing the project file or the IC models.
- Three advanced working modes:
A. Manual Mode: Press the“Start Button” to execute programming after inserting IC in all sockets.
B. Auto Detection Mode: Each socket works independently. Programming is executed instantly after inserting the IC into the socket.
C. Handler Mode: Use in the DediProg auto-handler system.

| Engineering Mode |
For engineers and experts to access advanced features for development, repair, etc. |
Production Mode |
For operators in production to control multiple sites and improve the throughput. |
Standard Package
- ProgMaster-U8 x 1
- USB Cable x 1
- Power Cable x 1
- 32G Memory Card
Optional Purchase
